VS-103E-3GSDI – 1080p60 Full HD Video Encoder with Embedded Audio

Model: VS-103E-3GSDI Manufacturer: Marshall Electronics

$2,340.00 USD

Description

Supports 60fps at 1920 x 1080 Resolution

  • 3G-HD/SD-SDI, HDMI and Composite video inputs
  • Encodes Audio Embedded from HD/SD-SDI & HDMI inputs
  • Dual Streaming (H.264/H.264, H.264/MJPEG)
  • MPEG2-TS Supported
  • Two Way Audio Communication (G.711, AAC)
  • HD/ SD-SDI, HDMI & Analog input Audio
  • Over 30 Types of PTZ Protocol Supported
  • Compliant with ONVIF, PSIA

Specifications

System System Mode Encoder
Encoding Mode Normal / MPEG2-TS mode
Network Network Interface Ethernet 10/100Base-T (RJ-45)
Network Protocol TCP/IP, UDP, Multicast, DHCP, SMTP, HTTP, HTTPS, SNMP, RTP, RTSP,PSIA, ONVIF
Video Compression Main Stream: H.264 Secondary Stream: H.264 / MJPEG
Data Rate 32Kbps ~ 8Mbps
Resolution 1920×1080/p60 ~ 352×240/30fps, 18 resolution step
PC Resolution HDMI Input format: 800 x 600, 1280 x 1024, 1440 x 900, 1440 x 900
Input 1 1 x HDMI type A, HDMI RX
Input 2 1 x Composite (BNC Type)
Input 3 1 x HD/SD-SDI (BNC Type) – (VS-103E-3GSDI only)
Motion Detection Sensitivity Adjustable
Audio Compression G.711 , AAC
Sample Rate G.711: 8KHz, AAC: 32KHz
Data Rate G.711: 64Kbps, AAC: 64Kbps, 128Kbps
Input 1 x Line-In (3.5mm Stereo) 2 channels of Embedded Audio
Output 1 x Line-Out (3.5mm Stereo )
Serial Port 1 1 x RS-232 (Terminal Block)
Port 2 1 x RS-422/485 (Terminal Block)
Data Rate 2,400bps ~ 115,200bps
Sensor Sensor Input 2 x NO Contact (Terminal Block)
Alarm Alarm Output 2 x NO Contact (Terminal Block)
Audible Beep 1 x Buzzer 88dB Min
User Interface System Status LED
Storage Recording/Backup 1 x USB 2.0 Port
Security Authentification 4 levels of user authentification, IP address Filtering, HTTPS Encryption
Software VMS 16 Included 16CH Recording & Live Monitoring with Search & Playback
Physical Dimension 134.08(W) X 125.5(D) X 36.87(H)mm / 5.28(W) X 4.94(D) X 1.45(H)in
Weight 504g / 1.11lb
Power Source DC 12V/0.8A, PoE (Power over Ethernet): 802.3af
Power Consumption Max 9.6W
Operating Temp. -10°C ~ 50°C / 14°F ~ 122°F
